K2 InsertionRail 2.0 CrossConnector T Set Black Anodised

This is the part that marries K2's two rail systems: the CrossConnector 2.0 T-Set fixes an InsertionRail 2.0 onto any K2 mounting rail beneath it.

Its one clever detail is where the screws sit. They are outside the mounted insertion rail rather than under it, so the rail and its connector can still be moved vertically on the mounting rail after everything is bolted up. Rows get squared off at the end instead of having to be perfect first time.

What the set contains

K2 supply this as a set. All accessories required for installation are included in this set. No separate bolts or nuts are ordered for the connection itself. Materials are aluminium EN-AW 6060 T66, stainless steel 1.4301 and A2-70, with TPC.

Order alongside

• K2 InsertionRail 2.0 – 30; 5.70m

  The insertion rail this connector carries.

• K2 InsertionRail 2.0 FixStop

  Sets and holds the rail position, once the connectors allow it to slide.

• K2 InsertionRail 2.0 Cover 30, 2.85m

  Closes the channel on 30 mm framed modules once the row is in.

• K2 InsertionRail 2.0 RailConnector

  Joins two insertion rails where the row is wider than one length.
