SunSynk Acure 5.0kW Single Phase Hybrid Inverter (White)
£793.05
ex VAT
Secure Checkout
14-Day Returns
Tracked Delivery
High Conversion EfficiencyMore of your solar reaches the home
MPPT TrackingMaximises yield in changing light
Grid CompliantMeets UK G98 / G99 requirements
SunSynk Acure 5.0kW Single Phase Hybrid Inverter (White)
- SunSynk Acure 5.0kW Single Phase Hybrid Inverter (White)
- Part No: SUN-ACURE-5.0
- Storage Systems - Hybrid Inverter
- Programmable, wireless smart switch (40 Amp switch included.)
- Max. 10 smart switches supported for Max power optimisation.
- Wireless CT coil facility.
- Built-in Bluetooth and Wi-Fi (no external data logger).
- Built in LAN connection.
- Brand new UI enhancing accessibility for users of all levels.
- Built in Arc fault detection.
- Built in solar panel theft detection circuits.
- Has multi-colour LED strip offering real-time insights of the system.
- Up to 16 units can be connected in parallel.
- IP65 rated.
- Intelligent air cooling.
- 5 Year standard warranty (Up to 10 years)
The Sunsynk Acure is a next-generation hybrid inverter designed for smarter, safer, and more efficient energy management across solar, battery, and grid systems.
Product Features
Warranty Information:
Warranty is applicable to 10 years when matched with a Sunsynk battery.
Equipment warranty registration needs to take place within 7 (seven) days of commissioning of the project, failure to register the warranty may result in the warranty being made void.
This product must be installed by a qualified electrician/technician. All installations must adhere to local wiring regulations and standards. ClearRay Solar will not be held liable for any product malfunctions as a result of incorrectly installed systems.
This product is G98 and G99 certified and can be checked on the ENA website using Sunsynk's reference.
High Efficiency 97.6 %More power from the same roof space
IP65 RatedBuilt for UK weather conditions
Technical Specifications
Rated Power (Pmax)5,000 W
Module Efficiency97.6 %
Battery Voltage40 - 60 V
MPPT Quantity2
Min MPPT Voltage150 V
Max MPPT Voltage425 V
Max Input Voltage500 V
Max DC Power8,000 W
Max AC Power (5 min)5,500 VA
Max DC Current18 + 18 A
Max DC Inputs2
Integrated DC SwitchYes
Height530 mm
Width376 mm
Depth276 mm
Weight19.35 kg
IP RatingIP65
Operating Temperature-40 °C to +60 °C, derating above +45 °C
Warranty5 years, or 10 years when installed with a Sunsynk battery
